A Versatile System for the College Classroom
Today's educators call for a classroom microscope that would be ideal for continued education and pre-clincial programs. Demanded is a product with crisp optics, ergonomic features for a mature classroom, and a price point that supports institutional purchases. Provided is the Lx 300, putting all requests to rest.
Lx 300 Advantages:
EP2 series Infinity Corrected Plan Achromatic objectives provide crisp and accurate images at all powers. The optical system allows for the introduction of digital accessories while maintaining the highest level of performance.
A Butterfly style binocular head will enable two distinct viewing positions for students of different heights, thus making the Lx 300 comfortable and versatile in use.
An eco friendly and highly efficient rechargeable LED (approx. 100,000 hours bulb life) serves as a powerful daylight color temperature illumination source that will make bulb change a thing of the past.
Microscope
| Stand |
Single mold sturdy stand with anti-rust materials. Ergonomic base for hand rest and greater stability. |
| Viewing Body |
Siedentopf Binocular (Butterfly style) or Trinocular head, 45° inclined, 360° rotatable, with adjustable viewing height up to 40 mm, IPD 48 - 75 mm |
| Eyepieces |
Wide field 10x/18 mm with foldable eye guards, lockable, antifungal |
| Nosepiece |
Reverse angle quadruple nosepiece (Ball bearing type) with click stops and rubber grip |
| Objectives |
EP2 Plan Achromat DIN Infinity objectives 4x, 10x, 40x (spring loaded), 100x (spring loaded, oil), antifungal |
| Mechanical stage |
Double plate stage 150 x 135 mm, X-Y travel range 75 x 40 mm with low-height controls. Hard coated surface for scratch resistance. Double specimen holder. |
| Condenser |
Sub stage Abbe condenser NA 1.25 with aspheric lens. Iris diaphragm with blue daylight filter. Rack and pinion movements on metal guides |
| Focusing |
Coaxial coarse and fine focus on ball drive system for smooth operation |
| Illumination |
Intensity controlled LED (up to 50,000 hours of LED life) |
| Electronics |
Universal input 100 - 240 V AC, 50/60 Hz. Built-in voltage stabilizer |
| |
|
Package Contents
- Power Cable (6ft)
- Cargille Immersion Oil
- Spare bulb (20w version only)
- Nylon Dust Cover & Cleaning Cloth
- Styrofoam Casing
Accessories (Optional)
- Pointers & Micrometer Reticules
- Phase (Simple & Zernike), Polarizing, Fluorescence and Dark Field Kits
- Dual Viewing Bridge
- Quintuple Position Viewing Bridge
- Auxiliary Objectives and Eyepieces
- Cord Hanger Kit
- Digital Cameras and Adapters
- Soft Carrying Case
Lx 300 Brochure
Learn more about the Lx 300's unique value offering.
|
User Manual
Learn all about the Lx 300, its functions, and more.
|
